Product Description
This machine features a three-head configuration: the first head uses a saw blade to cut the chamfer; the second head grinds and finishes the chamfer surface; the third head can be optionally equipped with either a grinding head or a cutting head to create an adhesive edge positioning groove.
The workbench features openings and is equipped with adjustable casters, facilitating easy loading/unloading of materials while preventing friction between the panels and the work surface.
This machine employs an integrated gantry machining center for precision molding, delivering exceptional accuracy with seamless chamfering. Its user-friendly operation makes it an ideal choice—a precision chamfering machine specifically designed for high-end slabs and stone materials, suitable for a wide range of customers.
Technical Parameters
Dimensions for plate machining | Outline dimension （m） | Table size | Total power | Machine tool weight | |||||||||||||||
Maximum: 3200; Minimum width: 40 | 5100×1950x1600 | 3200x400 | 15.5 | 1.6 | |||||||||||||||
mm | mm | mm | kw | t | |||||||||||||||
