Product Introduction
The JH-1131 is a specialized chamfering machine designed for precise edge profiling on stone slabs, including granite, marble, quartz, and engineered stone. Engineered for efficiency and accuracy, it performs chamfering, beveling, and edge finishing in a continuous operation, delivering clean, uniform edges with a smooth surface finish.
Built with a robust welded frame and high-quality guide rails, the machine ensures stable performance and consistent results even under continuous production. The adjustable chamfer angle and depth allow operators to quickly adapt to different specifications, making it suitable for a wide range of applications such as countertop fabrication, vanity tops, and architectural stone cladding.
Equipped with a user-friendly control interface and reliable motor drive system, the JH-1131 combines operational simplicity with industrial-grade durability, making it an ideal choice for stone processing workshops and factories seeking consistent edge quality and high productivity.
Performance characteristics
The XZM-1131 stone plate chamfering machine is suitable for factories where small-piece chamfering (43°) accounts for more than 80% of production. It is designed for seamless splicing processes, primarily engaged in the processing of sanitary washbasins. The product is divided into three configurations: the manual type adjusts the lifting and lowering of grinding heads after abrasive wear through manual handles; the electric type allows the grinding head to be adjusted up and down via an electric button after abrasive wear.
Technical Parameters
Stone Conveying Speed | Voltage | Minimum Processing Size | Stone Processing Thickness | Power | Dimensions | Weight |
0.5-5m/min | 380v/50Hz | 50mm×50mm | 3-25mm | 23.5kw | 6200×1000×2500mm | 2300kg |
Distributionof grinder
